Anti-vandal LED luminaire designed for areas with a high risk of damage.

DALI regulation DALI regulation
Mechanical resistance (IK9) Mechanical resistance (IK9)
Degree of protection (IP66) Degree of protection (IP66)


Electrical parameters

Light source LED
Power voltage AC 220–240 V / 50–60 Hz
Connection method terminal block (supplied without cable)
Ballast part electronic driver with integrated surge protection
Possibility of regulation without regulation (not labeled), DALI (DALI), NightDIM (AD)
Emergency module NO

Light parameters

Optical system diffuser
Light distribution direct
Colour rendering index Ra > 70, Ra > 80
Colour temperature 2 700 K » 3 000 K » 4 000 K
Service life > 100 000 hod. (L90B10)


Luminaire body powder-coated steel sheet
Colour RAL 7016, other RAL (on request), exterior finish (V)
Surface type gloss
Luminaire cover glass diffuser, opal (DPO)


Protection class I, II
Maximum ambient temperature -30 / +40 °C
Protection of the luminaire's electrical part IP 65
Protection of the luminaire's optical part IP 65
Mounting on normally flammable surfaces YES
Shock resistance IK 10


Method surface mounted, corner mounted
Recommended height from 2 to 6 m


Clips NO
Suspension accessories corner holder (to order) » mounted holder (to order)
Notes luminaire is equipped with security screws are for protection against theft
Use garages, jails, passages, pedestrian underpasses

Luminaire is equipped with security screws are for protection against theft.


Optical and electrical parameters tolerance ± 10 %


Energy label

Energy label
