Specifications
Electrical parameters
| Light source | LED chips SM0 |
| Supply voltage | AC 220–240 V / 50–60 Hz |
| Connection | Pre-wired cable |
| Control gear | Electronic driver with surge protection L/N-PE 10 kV |
| Surge protection | Additional 10 kV surge protection (S) |
| Fuse protection | 6,3 A fuse (J) |
| Control options | Non-dimmable (no marking), DALI (DALI), virtual midnight (A) Ready for NEMA wireless communication (N), Zhaga (Z) or 2× Zhaga (Z2) |
| Constant Lumen Output | CLO (C) |
Light parameters
| Optical system | M-class roads (Mxx), L-class roads (Lxx), reflector (Pxx) Area (Uxx), combined (Kxx), 2×2 optics, 30 optics types BACK Light shields (BL1/BL2), FRONT Light shields (FL1/FL2) |
| Light distribution | Direct |
| Colour rendering index | CRI > 70 |
| Colour temperature | BLUE FREE™ (AMBER), TW (1,700–3,000 K) 2,200 K / 2,700 K / 3,000 K / 4,000 K / 5,000 K / 5,700 K |
| Lifetime | > 120,000 h (L80) |
Safety
| Protection class | I, II |
| Max. ambient temperature | -40/+55 °C |
| Ingress protection | IP 66 |
| Impact resistance | IK 08 |
Mounting
| Mounting method | Installation with 4 mounting clips |
